Engine Type
|
Single cylinder ,4 stroke ,air-cooled
|
|
Displacement
|
125cc（119.6）
|
|
Compression Ratio
|
9.6:1
|
|
MAX POWER OUT
|
5.5kW/8500r/min (kW/r/min)
|
|
Max Torque
|
6.9N.m/6500r/min (N.m/r/min)
|
|
Gear shift mode
|
One forwards and one reverse with hand gear shift
|
|
Carburetor
|
PZ20
|
|
Ignition
|
AC-CDI
|
|
Starting System
|
Electric
|
|
Transmission
|
CHAIN
|
|
Suspension / Front
|
Traverse Double-arm
|
|
Suspension / Rear
|
Non-independent suspension
|
|
Brakes / Front
|
Drum brake
|
|
Brakes / Rear
|
Disc brake
|
|
Tires and Rim/ Front
|
19X7-8 20F
|
|
Tyre and Rim/ Rear
|
18X9.5-8 25F
|
|
Dimension L x W x H
|
62" x 38" x 37"
|
|
Carton L x W x H
|
58" x 31" x 26"
|
|
Seat Height
|
27.5"
|
|
Wheelbase
|
37.7"
|
|
Front Wheel tracy
|
30.9"
|
|
Rear Wheel Tracy
|
26.3"
|
|
Fuel Capacity
|
2.2L
|
|
Net Weight
|
236LBS
|
|
Gross Weight
|
289LBS
|
|
Ground distance
|
5.5"
|
|
Max payload
|
143LBS
|
|
Payload of rack（Front/Rear）
|
F :22LBS/R :22LBS
|
