Item

Technical

Unit

Vehicle

 Vehicle Size

1860*1050*1340

   Wheelbase

1210±20mm

Front wheel spacing

810mm

Rear wheel tread

800mm

Minimum ground clearance

265±15mm

SEAT HEIGHT

835±15mm

CHASSIS HEIGHT

295mm

HANDLE HEIGHT

1120mm

Package size, l × w × H

1950*1130*820mm   36/40H

Front mechanical hitch travel

75

Rear mechanical hitch travel

90

Minimum turning diameter

3400±500mm

Steering angle

<45°  （actual39°）

Sides lip

<5m/km

  Rated load mass

100kg

net weight

197kg

 Gross weight of packing

225kg

 Brake type (front / rear)

Front and rear hydraulic brake

Brake control mode (front / rear)

Front hand brake and rear foot brake

Rim type (front / rear)

10寸

Tire size (front / rear)

21*7-10/22*10-10

Tyre pressure (front / rear)

9P.S.I

Transmission mode

 Chain

Engine

Model

JN1P63QMK

type

Four stroke, oil cooling + forced air cooling, balance shaft, horizontal

Production unit

Juneng

Bore x stroke

 62.5 ㎜*57.4 ㎜

 cylinder

177.3ml

Compression ratio

10：1

Rated power and corresponding speed

7kW/7000r/min

Maximum power and corresponding speed

7.3kW/7500r/min

 Maximum torque and corresponding speed

10N·m/6000r/min

Minimum no-load stable speed

1700±100r/min

Minimum fuel consumption rate

367g/kW·h

Fuel grade

93#

Lubrication mode

Pressure and splash mixed lubrication

Brand of lubricating oil

SAE 80W/90SF class SAE 15W / 40 (crankcase) gearbox: SAE 80W / 90

Clutch type

Automatic centrifugal dry

Starting mode

E-start

Ignition mode

C.D.I

Parts

Chemical / injector model or type description

Injection

Spark plug model or type description

C7HAS（NGK）、A7T or A7RT

Battery

12V，9HA

Headlamp model or type

12V 55-55W

technical

 Maximum speed

60km/h

Starting performance

15S

Braking performance

≤5.9m/30m/km/h

前轮力和F/ wheel force

≥60%

前轮力差F/ wheel force differential

≤20%

后轮力和R/ wheel force

≥55%

后轮力差R/ wheel force differential

≤24%

climbing performance

21°

Parking performance

≥18%

Emission index

CO(%)

≤2

HC(PPm)

≤250

Maximum noise dB (A)

≤82 dB(A)

Starting acceleration performance (s)

≤18

Beyond acceleration (s)

≤15

Accessories

Tank volume

9.7L

Front / rear shock absorber type

Hydraulic damper

Type of exhaust muffler

Tube type impedance composite muffler

Front /rear shock absorption length

345mm/350mm
